TrueVue 15

TrueVue 15
Add to Shopping List
Add to Shopping List

TrueVue products are ‘dual reflective’ – reflective on the outside to maximize heat rejection and neutral on the inside to maintain views.

Key Benefits

  • Reflective exterior maximizes heat rejection resulting in excellent energy savings and payback time
  • Low interior reflectance maintains views to the outside, especially at night
  • Contains our darkest product which can reduce glare by up to 94%
  • UV blockers protect people and property from damaging UV rays

$146.00$966.00

Specification TrueVue 5 TrueVue 15 TrueVue 30 TrueVue 40
Visible light transmittance % 5% 12% 31% 39%
Visible light reflectance (exterior) % 44% 44% 22% 14%
Visible light reflectance (interior) % 8% 23% 13% 10%
Solar heat gain coefficient 0.21 0.23 0.39 0.48
Total solar energy rejected % 79% 77% 61% 52%
UV Tdw-ISO @ 300 to 700 nm % 4% 10% 23% 28%
UV light blocked (300 to 380 nm) % >99% >99% >99% >99%
Fade Reduction % 95% 88% 72% 66%
Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4″ (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.
Weight N/A
Dimensions N/A
Roll Size

36"x100', 36"x25', 36"x50', 36"x75', 48"x100', 48"x25', 48"x50', 48"x75', 60"x100', 60"x25', 60"x50', 60"x75', 72"x100', 72"x25', 72"x50', 72"x75'
