Sentinel Plus DX 5

$152.00$1,056.00

Sentinel Plus DX 5
Add to Shopping List
Add to Shopping List

Sentinel Plus is Solar Gard’s range of exterior window films – which provide maximum heat rejection by being the first line of defense against solar heat and glare. The Sentinel Plus range includes Stainless Steel, Silver, Clear, and SX.

Key Benefits

  • Filming the exterior maximizes heat rejection with up to 82% Total Solar Energy Rejected
  • Provides a refreshed and uniform look to dated buildings
  • Maximum heat rejection also means maximum saving on air conditioning costs
  • UV blockers protect people and property from damaging UV rays
Specification Sentinel Plus DX 15 Sentinel Plus DX 5
Visible light transmittance % 14% 5%
Visible light reflectance (exterior) % 42% 60%
Visible light reflectance (interior) % 17% 15%
Solar heat gain coefficient .25 .14
Total solar energy rejected % 75% 86%
UV Tdw-ISO @ 300 to 700 nm % 11% 4%
UV light blocked (300 to 380 nm) % >99% >99%
Fade Reduction % 87% 95%



Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4″ (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

Sentinel Plus is Solar Gard’s range of exterior window films – which provide maximum heat rejection by being the first line of defense against solar heat and glare. The Sentinel Plus range includes Stainless Steel, Silver, Clear, and SX.

Key Benefits

  • Filming the exterior maximizes heat rejection with up to 82% Total Solar Energy Rejected
  • Provides a refreshed and uniform look to dated buildings
  • Maximum heat rejection also means maximum saving on air conditioning costs
  • UV blockers protect people and property from damaging UV rays
Specification Sentinel Plus DX 15 Sentinel Plus DX 5
Visible light transmittance % 14% 5%
Visible light reflectance (exterior) % 42% 60%
Visible light reflectance (interior) % 17% 15%
Solar heat gain coefficient .25 .14
Total solar energy rejected % 75% 86%
UV Tdw-ISO @ 300 to 700 nm % 11% 4%
UV light blocked (300 to 380 nm) % >99% >99%
Fade Reduction % 87% 95%



Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4″ (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.
